Automatic Rotary Type Air Blowing Injection Moulding Machine Views:550
  • Product Information
  • Specifications
  • Product Image
  • Production Video
  • Foundation Plans
  • 1.  Equipped blowing system, the product are lightweight soft and shining, the weight would be 20 %-30 % less then than made in conventional way.


    2.  Re-cycle material can be injected. The products have a good quality and super lightweight, which is almost the same as those made by all new material.


    3.  The automatic hydraulic mould-opening structure combine with the control system to make the movements fast and positive, as well labor saving.


    4.  Unique structure design with mould cooling device for improving the production.


    5.  Use touch screen and controlled by programmable controller , the machine have the self-diagnostic function, which make it can be maintained quickly.


    6.  Pressure system, material volume and mould-clamping can be controlled individually with different mould, making products perfactlly.


  • Automatic Rotary Type Air Blowing Injection Moulding Machine

    项目

    ITEM

    UNIT

    KM-116B1

    KM-120B1

    使用原料

    Raw Material


    PVC/TPR

    工作站數

    Work Stations

    Stations

    16

    20

    合模力

    Mold Clamping Force

    kg

    70000

    70000

    容模空間

    Space for Mold(L*W*H)

    mm

    450*270*200

    螺桿直徑

    Screw Diameter

    mm

    70

    ******射出量

    Max.Injecting Capacity

    cc

    760

    射出壓力

    Injecting Pressure

    kg/cm2

    1200

    射出速度

    Injection Speed

    cm/sec

    10

    螺桿轉速

    Rotating Speed of Screw

    r.p.m.

    0-165

    溫控段數

    Temperature Control

    sections

    4

    料管電熱能量

    Heating Power of Barrel

    kw

    8.3

    電機

    Electricity

    HP

    25HP*1,2hp*1

    總用電量

    Total Electricity Consumption

    kw

    29

    機器尺寸

    Machine Dimension L*W*H

    mm

    5880*2920*1770

    6380*3150*1770

    機器重量

    Machine Weight

    kg

    7000

    7500
